Professional MA certificate Explosion proof Camera with IR laser infrared proof camera housing Support POE solar power supply

FOB Reference Price:Get Latest Price
US $1-499 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
SafeEye
Model Number:
S-KBA112R
Type:
IP Camera
Style:
Bullet Camera
Sensor:
CCD
Technology:
Infrared
Special Features:
Vandal-proof
Image sensor:
1/2.7'' SONY cmos CCD
Signal System:
PAL/NTSC
camera module:
Analog/AHD/Network/SDI(option)
Minimum illumination:
0.01LUX/0Lux(infrared on)
IR distance:
50m-80m-100m
Ex mark:
ExdIIBT6 / ExdIICT6 IP68
Work voltage:
AC100V~220V,AC24V/DC12V
Material:
Stainless steel 304/ 316L
IP Grade:
IP68
For the environment:
geyser / Oil / Coal / underground mines
Supply Ability
Supply Ability:
9000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Special Packaging for Explosion-proof camera
Port
ShenZhen
Lead Time :
Shipped in 7 days after payment
Video Description
Product Description
Professional MA certificate Explosion proof Camera with IR laser infrared proof camera housing Support POE solar power supply


The explosion-proof performance accord with GB3836.1-2000 << Electrical apparatus use general requirements:Part1,which used under explosive gas atmospheres environment>>, GB3836.2-2000 << use explosion-proof electrical equipment under explosive gas environment : Part 2, Exd explosion proof "d" >> standard and make Exd explosion proof structure.

Explosion-proof level :
ExdⅡCT6 / ExdⅡBT6

Product Material:
high quality Carbon steel(optional to select to use stainless-steel material in corrosion environment

Functions and Features:
infrared to see in 30m/60m/80m distance etc.
Use unique special explosion proof glass, high light flux rate,avoid infrared light spot
Nanometer invisible features, rain wiper functions,non-stick water,non-stick oil,Exclusion of dust
High hardness and high quality carbon steel material, surface coated processing technology
Optional to add some functions according to customer requirements: e.g:
internet module,Optical transceiver module,wireless transceiver module, heating device

Work Environments :
Chemical industry,Coal mine,oil,steel,iron,Military project,medicine,mine,oil warehouse,ship,oil drilling platform,gas station,Production of fireworks and firecrackers,food Processing and storage




The features
1·Double explosion-proof certification, slightly high-risk places for a variety of evil.
2·2 million pixels 1/3 "CMOS sensor, the maximum resolution of 1920 x 1080.
3·Using 3 million pixel hd IR infrared lens, focus is not migration at night.
4·Focal length range: 2.8-12 mm manual focusing, automatic aperture.
5·Adopt high efficiency infrared lamp array, long service life, irradiation distance of up to 100 meters.
6·ICR infrared filter plate automatic switch, achieve real monitoring day and night.
7·Support 3D digital noise reduction, wide dynamic support Numbers.
8·Advanced video compression technology, high compression ratio, and processing is very flexible, low bit rate.
9·Supports dual stream, mobile phone monitoring.
10·The window glass surface by nanotechnology, high luminous flux rate, non-stick water, non-stick oil, to exclude dust.
11·Low power consumption, low consumption, the fuselage internal air convection heat dissipation design, can work continuously for a long time
12·A variety of power supply mode is convenient, AC220V/DC12V (if need other po-wer supply can be customized).
13·Options of semiconductor components controlled temperature, automatic heating
and cooling function.
14·Adopt stainless steel material manufacturing. Suitable for the corrosive environ-Ment.



Explosion Proof Infrared Fixed Focus Lens Camera Sprcifications Technical Parameters:

Product modelS-KBA112-IP2
Explosion-proof gradeExdIICT6
The camera
Imaging deviceSONY1/3 "CMOS sensor
minimum illumination0.1 lux f1.1 color, black and white 0.01 lux f1.1
The focal length2.8 to 12 mm(manual focus)
Aperture controlautomatic
Automatic apertureDC drive
To switch betweenICR automatically switches
dayand night
The shutterA third second to 1/100000 of a second
Digital noise reduction3 d digital noise reduction
Infrared distance30 to 100 m
Network parameters
Video compression H.264/H.265
standard
H.264 encoding typesBaseLineProfile/MainProfile
Compressed output bit rate32Kbps~8Mbps
Frame rate2 million and below 25 frames (real-time), adjustable support 1 ~ 25 frames per second
Image outputMain stream:1920x1080,1600x1200,1280x1024,1280x960,1024x768,1280x720
Subcode flow:640x360,480x270,352x288,320x240,352x192,320x192,288x192,256x192
Interface protocolsONVIF,PSIA,CGI,ISAPI,GB28181
Support agreementRTSP/FTP/PPPOE/DHCP/DDNS/NTP/UOnP Network protocols such as
Mechanical properties
The materialStainless steel 304 or 316 (use strong corrosive environment such as chemicals, acid and alkali)
Surface treatmentStainless steel primary colors or electrolytic polishing
Protection gradeIP68
Into the line hole specification2 G3/4 "into the thread hole
General specification
The power supply voltageDC12V/AC220V/POE power supply (optional)
Temperature range- 40℃ ~ 60℃
Relative humidityNo more than 95% (+ 25 ℃)
Atmospheric pressure80 kpa to 106 kpa
Constant temperature systemoptional
dimensions360mm ×260×140mm
weight8.5Kg



 S-EX-HS-9net566bacedNa0723243
Company Information

Why Choose SafeEye ?



(1) 24 hours reply



(2) 2 years Warranty



(3) 100% 5 steps Quality Check



(4) Powerful R&D team,  OEM hardware and software



(5) fast leadtime: 3-4 days for sample order, 5-10 days for leadtime


Our Services
  1.  The product is based on Ex-works for 1-50pcs, FCA shenzhen for 50-500pcs, FOB shenzhen for above 500pcs.
  2.  Payment term:100% payment in advance before shIpment (T/T, Western Union ,paypal,cash or any other means at your convenience)
  3.  Delivery Time:sample order: 1-3 working day, Normal order:longer than 3 working days according to the order quanity
  4.  All the above products have CE ,FCC and ROHS certificates
  5.  Welcome OEM & ODM order,MOQ for OEM is 50pcs/model
  6.  Power adapter isn't included in above prices, it's optional
  7.  Price Validity: 30 days from issuing date.
  8.  Warranty: 2 years after receiving goods,unlimited lifetime Technique support.
  9. If quanity more than 100pcs one model, we will free supply some camera parts for preapre exchange

       warranty-2






Packaging & Shipping

1.The package will be shipped from China via Express air or by sea as your request. The tracking number will E-mail to you when the item sent, usually it takes 4~5 working days to arrive by air;it takes 10~45 days to arrive by sea depending on the port.



2. Air freight (we have strong cooperation with DHL, TNT, FEDEX, EMS, you can also choose your own shipping forwarder)



  • DHL (3-7 business days)
  • FedEX (3-7 business days)
  • UPS (3-7 business days)
  • EMS (5-9 business days)
  • Air mail (7-25 business days)
  • The shipping way depends on your address.
FAQ

What the Payment terms:

T/T,Western Union,VISA,Mastercard,Escrow, paypal and so on.
1. We can arrange to produce in advance once we get the bank slip of deposit.
2. Order value less than 20,000USD, 100% payment before production;
3. Order value more than 20,000USD, 30% deposit. 100% paid before shipment.
Q.May I print our company logo on package box and products?
A:Of course,buyer logo is welcome in our company.We have one production line for printing buyer logo.
Q.Do you provide warranty for your products?
A:Yes,we promise two years warranty for all our products.
Q.What is Minimum Order Quantity?
A:Min Order Quantity is 10pcs,but sample order is welcome.
Q: Can We to be your Agency in our Country?
A: Of Course, welcome to be SafeEye Security Products agency in your country, we will try best support for you.



  Click “send” to get the latest price list from us.
